• Wall thickness 44 mm T&G • Wall Boards are flat faced with not rounded edges • Triple grooved interlock • The corbel of the roof around the whole cabin • Double glazed windows and double door with original decorative beading • Side span roof or the porch are supplied as optional extras • The cabin includes the floor and roof construction • The doors and the windows can be supplied either left, or right-hand *If you are going to assemble the cabin by yourself, please keep in mind that you will need a screws and nails to fix the floor and roof boards and bitumen shingles. * Shingles are supplied as optional extras
Additional Info

Additional Information

Description Basement size: 4.84 x 4.84 m (without veranda) Height overall: 2.7 m Double 2xglazed Door: 129,5 x 186 cm Double 2xglazed Window in Front: 138 x 91 cm Double 2xglazed Side Window: 138 x 91 cm Canopy: 1 m Roof length: 5.98 m Roof area: 35 m2 Building your log cabin or garden building is easier than you may think, no specialist skills are required to assemble the kit. Detailed instructions accompany each log cabin kit. Piece by piece the components fit together to create a garden structure that is at once appealing and enduring. Thorough preparation is the key to success. Familiarise yourself with the instructions, floor plan, and component list before unloading the pallet. Make sure the ground is firm and level. Before you begin to build a cabin you should check that you have a complete set of components and logs. Check each piece off against the parts list (see Parts List and Plans) as you remove it from the transit packaging. All logs and parts have a sticker, which will help you to rapidly find it position in log cabin. Please see explification of each wall before. Fist number of wall logs means level, starting from the bottom. Usually one wall corresponds to certain axis on cabin scheme. If, for instance, wall log number on the sticker is 1-B-12 you should read as first log from the bottom, on axis B. In the unlikely event that there is a missing component, or that a component has been damaged in transit and log is not usable not more, please contact your local supplier, quoting the cabin unique number displayed on the back list of log cabin assembly guide. They are impregnated with a long-lasting preservative which makes them darker than the other timbers. Check that the cross- diagonals are equal. Equal cross-diagonals mean that your cabin is square. Follow the cabin assembly guide and erect structure step by step till the roof. read more about log cabin assembly
Wall thickness (mm) 44
Window glass Double glass
Number of windows 2
Roof height, m 2.7
Roof planes Gabled
Wall height, m No
Size, m 5x5
Floor Type Wooden
Number of Doors 1
Roof area, m² 35
Front window size 138 x 91
Side window size 138 x 91
Door size, cm 129,5 x 186
